Low Rider ST / Sport Glide Tour Pack Mount Install from HOGWORKZ® + Tour Pack Liner Install

Adding a tour pack to your Harley® Softail Low Rider or Sport Glide! Get the ultimate luggage flexibility on the fly with this a Tour Pack Mounting Rack by HOGWORKZ®.

Almost indestructible & extremely comfortable. Forged from heavy duty steel, this durable design is built to last. Expertly engineered for a tight, rattle free, flawless fitment.

*Note: Low Rider models will require license plate relocation, or license plate laydown kit.

Part 1: Removing OEM Components and Installing HOGWORKZ® Docking Hardware

360_20250612095700

1. Remove Saddlebags:

  • Open your saddlebags and pull the lever on the inside out.
  • Rotate the lever until you see the flag sticking up.
  • Close the saddlebag and Slide the saddlebag back slightly to remove it.
360_20250612095929

2. Remove OEM Docking Hardware:

  • Locate and remove the existing OEM docking hardware.
360_20250612140823

3. Install HOGWORKZ® Docking Hardware:

  • Identify the appropriate HOGWORKZ® docking hardware for your setup (with or without saddlebags).
  • For saddlebag compatibility, use the 2mm spacer in the front and the 5mm spacer in the rear.
  • Place the spacers on the mounting points.
  • Use a 7/32" Allen wrench to install the hardware.
  • Important: Place your hand behind the mounting area to hold the backing plate in place while screwing in the hardware to prevent it from pushing out.

Part 2: License Plate Relocation (if using a solo mount and an OEM seat)

Note: If you are using a solo tour pack mount with an OEM seat, you may need a lay-down license plate bracket to prevent interference. If you are using a different seat that provides more clearance or a two-up mount, you might be able to skip this section.


1. Remove License Plate:

  • Unscrew and remove your license plate.
360_20250612142331

2. Remove OEM License Plate Bracket:

  • Remove the 7/16" nut on the backside of the bracket and the corresponding part of the bracket.
  • Locate the three Phillips head screws attaching the bracket to the fender.
  • Use a 7/16" wrench on the underside of the fender to hold the nuts while removing the screws.
  • Start by removing the lower two screws, then the top screw.
  • Remove all parts of the OEM bracket.
360_20250612142848 360_20250612143236

3. Install New License Plate Bracket (if supplied in kit):

  • Place the rubber spacer (supplied in the kit) against the fender first.
  • Reuse the three screws that you took out with the original bracket.
  • Feed the screws through the new bracket and the fender, lining them up.
  • Secure with the nuts on the underside using the 7/16" wrench.
  • Place your license plate inside the outer bracket from the backside. The bracket is curved, so you may need to gently bend the plate into place.
  • Use the supplied four screws (or your original screws) with a 4mm Allen wrench.
  • Loosely seat all four screws first, then tighten them all the way down.

Part 3: Attaching the Tour Pack to the Mount

1. Prepare for Mounting:

  • Call a friend to help hold the tour pack mount.

2. Position the Base Plate:

  • Open your tour pack and place the base plate inside the tour pack with the HOGWORKZ® logo facing the front of the tour pack.
  • Line up the base plate over the four pre-drilled holes.

3. Insert Screws:

  • Take the supplied four screws and set them loosely into the holes from the inside of the tour pack.
360_20250612143713

4. Attach Mount to Tour Pack:

  • Close the tour pack.
  • While your friend holds the tour pack mount, set the tour pack down so the screws go into the slots on the mount.
360_20250612144132

5. Secure with Washers and Nuts:

  • Open the tour pack again and hold onto the screws from the inside of the tour pack to prevent them from flipping.
  • Place a washer and then a nut onto each screw from the underside of the mount.
  • Use a 7/16" wrench to hold the nut from the underside and tighten all four screws securely.

Part 4: Installing the Tour Pack onto the Motorcycle

360_20250612145259

1. Position the Tour Pack:

  • With the tour pack now attached to its mount, align the front of the tour pack mount with the front docking points on your motorcycle.

2. Engage Latches:

  • Line up the latches on the tour pack mount with the rear docking points.
  • Lock the latches into place.

Part 5: Final Touches and Accessories

1. Reinstall Saddlebags:

  • Once the tour pack is securely installed, reinstall your saddlebags.
360_20250612145611

2. Install Tour Pack Backrest Pad:

  • Choose either the slim or wrap backrest pad.
  • Follow the instructions provided with your backrest pad to install it on the tour pack.
360_20250612145844 360_20250612150334

3. Install Tour Pack Liner (Optional):

  • Remove the Tether:
    With the tour pack closed, remove the two screws that attach the tether to the tour pack lid. This will detach the tether.
  • Install Bottom Liner:
    Place the sticky velcro (if supplied) on the bottom of the tour pack.
    The liner has stitched-in velcro, so it will adhere to the bottom.
  • Install Top Liner:
    Run the detached tether through the designated portion of the top liner.
    Place the top liner inside the tour pack lid, ensuring the velcro adheres.
    Reattach the tether to the tour pack lid using the two screws you removed earlier.
